1-24KVA RMI-P Series Inverter
EverExceed RMI series is a new hot-swappable HF modular inverter with advanced technology and high efficiency. This inverter has been designed to offer low cost per VA and offers our standard features, high level of intelligence, reliability and smart characteristics. It has high operational reliability with smart monitoring & plug and play installation.
1KVA/2KVA/3KVA
Quantity:
EverExceed RMI series is a new hot-swappable HF modular inverter with advanced technology and high efficiency. This inverter has been designed to offer low cost per VA and offers our standard features, high level of intelligence, reliability and smart characteristics. It has high operational reliability with smart monitoring & plug and play installation.
Key features
 |  |  |  |
| Digital control | N+1 parallel redundant design | High operational reliability | Module built-in bypass |
| It adopts 32-bit DSP full digital and high-frequency SPWM technology, featuring strong anti-interference ability, fast calculation speed, high intelligence, accurate control precision and pure output waveform. | It can form an N+1 parallel redundant power supply system. The modules are backup each other, with high reliability and flexible configuration. | The operation and parallel connection of each module are independently controlled by the built-in DSP, no single point of failure, independent flow between modules. | Users can choose inverter priority or bypass priority. |
 |  |  |  |
| Plug and play | Smart monitoring | Complete protection | High power density |
| No need to do any parameter setting and operation, the module automatically enters the normal working state, maintenance and replacement is simple and fast. | Indicator panel, fault sound and light alarm, RS485 communication interface and fault dry contact. | It has the functions of input over-voltage, output over-voltage, over-temperature, short-circuit and so on. | 1/2 19〞 width design, the volume is only half the width of the conventional inverter, saving space and convenient parallel. |
Technical specifications
| Product Parameters | Rated Power | 1KVA | 2KVA | 3KVA |
| Size （W×H×D）(mm) | 9.5"/1U | 9.5"/2U | ||
| 216*44*426 | 216*88*421 | |||
| Input Parameter | DC Input Voltage | 48VDC/220VDC | ||
| DC Input Range | 42～59VDC/190～270VDC | |||
| Bypass Input Range | 176～264(Can be adjustable according customer) | |||
| Bypass Switch Time | 5～12ms | |||
| AC Output | Rate Output Voltage | 220VAC | ||
| Rate Output Frequency | 50Hz | |||
| Load Regulation | <1% | |||
| Frequency Accuracy | <0.1% | |||
| Crest Ratio | 3:1 | |||
| Waveform Distortion | Resistance full load＜3%，nonlinear full load＜5% | |||
| Dynamic Response | Voltage transient range＜3%, transient response recovery time≤60ms（load from 0 to 100%） | |||
| Parallel Uneven Flow | ＜3% rated current RMS | |||
| Overload Capacity | Load current ＜105%, continuous work | |||
| Load current 105～125%, continuous work 10min shutdown | ||||
| Load current 125～150%，continuous work after 1min shutdown | ||||
| Load current＞150%，after 20ms shutdown | ||||
| Protection Function | Input connection protection, input under voltage and over-voltage protection, output overload protection, output short circuit protection, over temperature protection | |||
| Communication | Communication Interface | RS485 | ||
| Work Environment | Insulation Strength | 2kVAC，1min | ||
| Noise (1m) | ＜45dB | |||
| Operating Ambient Temperature | －10～50℃ | |||
| Transport And Storage Temperature | ‘- 40～70℃ | |||
| Relative Humidity | 0～90%, no condensation | |||
| Relative Altitude (m) | ≤3000m，1500～3000m, 1% decrease in output for every 100 m increase | |||
